Front/Back Access Indoor/Outdoor LED Video Wall with 500*500mm Panel (P3.91, P4.81)

Indoor/Outdoor LED Video Wall with Front/Back Access
Cabinet size of 500*500 mm or 500 * 1000 mm better for different screen sizes

Quantity:
  • P3.91
  • Video Display
  • 1R,1G,1B
  • 1/16
  • LED Video Display
  • IP43
  • SMD2121
  • 64*64dots
  • Die-Casting Aluminum
  • Wooden Case or flight case
  • Shenzhen China
  • Full Color
  • 3.91mm
  • 65536dots/Sq.M
  • Win XP,Win 2000,Win7/8,Nt
  • Stage Performance, Advertising, Shopping Guide
  • CE, RoHS, CCC, FCC
  • 250mm * 250mm
  • 500*500mm
  • PRT
  • CE, FCC, Rohs
  • 8528591090
New design Rental led panel with independent modules and magnetic fixing design for both and front maintance,panel size of 500x500mm,
also can be 500x1000mm for indoor or outdoor fixed or rental use,can be used for P3.91,P4.81 and P6.25.


1.Popular and multifunction cabinet design, available for various application,only need to replace the module with different pixel pitchs and keep the same cabinet,save cost

2. Made with die-casting Aluminum material, keep strong struction and durable, long life span

3. Independent and integrated control box for quick replacement and convenient maintenance

4.LED Modules absorbed on the frame with magnets tightlyeasy to assemble and maintenance

5.Panel frame support different mode(different pixel pitch),available for P4.81, P3.91 and P6.25

See more pictures for good understanding and contact us for details

Front/Back Access Indoor/Outdoor LED Video Wall with 500*500mm Panel (P3.91, P4.81)Front/Back Access Indoor/Outdoor LED Video Wall with 500*500mm Panel (P3.91, P4.81)Front/Back Access Indoor/Outdoor LED Video Wall with 500*500mm Panel (P3.91, P4.81)
Front/Back Access Indoor/Outdoor LED Video Wall with 500*500mm Panel (P3.91, P4.81)Front/Back Access Indoor/Outdoor LED Video Wall with 500*500mm Panel (P3.91, P4.81)


P3.91 SMD2121 Indoor full Color LED Screen Specification
Pixel pitch 3.91mm
Pixel Configuration 1R1G1B
LED component SMD2121 black
Size of module 250mm x 250mm
Resolution of module 64x64dots
Size of cabinet 500x500mm/500mm x 1000mm x 75mm
Resolution of cabinet 128x128/128x256 dots
Material of Cabinet Die-casting
Weight of Cabinet 8kgs/14kgs
Brightness >1600cd/sq.m
Density 65746dots/sq.m
Best viewing angle 140 /140
Pixel Configuration 1R1G1B
Best viewing distance 3-50M
Maximum power consumption 1200W/sq.m
Average power consumption 640W/sq.m
Driving method 1/16 scan
Control method Synchronization
Gray scale 65536
Colors 256*256*256
Color temperature 3200-9300k
Uniformity 97%
Working voltage AC220V/110V±10%
Working temperature -20ºC~+50ºC±10%
Working humidity 10% ~ 90%
MTBF 10,000 hours
Frame frequence 50/60Hz
Refresh frequence >1920Hz
IP grade IP31
Life Span 100,000 hours
Data transafer method RJ45
Pratical standard CCC  TUV-CE  ETL etc.
Effectivce Communication
Distance(without relay)
Unshielded twisted pair net line transmission distance:100M, max transmission distance:130M; Multi-mode optic fiber: 500M;
Single-mode optic fiber: 10KM
Accepting signal with video processor PAL/NTSC/SECAM,S-Video;VGA;RGB;HDMI,DVI,Composite Video;SDI,DP etc.
Systems operating platform WINDOWS(WINXP,WIN7/8/10), and interfaces for secondary development
