576X576mm Full Color LED Screen/Display Panel for Stage Background (P4.8, P6)

Quantity:
  • P4.8
  • Video Display
  • 1R,1G,1B
  • 1/16 Scan
  • LED Video Display
  • IP31
  • 576X576mm
  • 288X288mm
  • PRT
  • CE, FCC. ROHS, 3C
  • 8528591090
  • Full Color
  • 4.8mm
  • 23042dots/Sq.M
  • Win XP,Win 2000,98,Win7/8
  • Stage Performance, Advertising, Shopping Guide
  • CE, RoHS, CCC, FCC
  • Die-Casting Aluminum
  • 60X60dots
  • Flight Case or Wooden Case
  • Shenzhen
P4.8 Full Color led display screen/display panel with die-casting size of 576x576mm for indoor rental,with high contrast, high definition and good uniformity,

Product Description:

1. Made with black body SMD3535 LEDs, keep wide view angle to 140 degree for horizontal and vertical,high contrast ratio 5000:1

2.. Made with die-casting aluminum,strong profiles with beautiful outlooking and durable,long life time

3. Slim and small cabinet size of 576× 576× 60mm,only 10.5kgs,light weight and portable by one hand

4. Flight case package,convenient to transport and collect,good protection

5. Rental design, easy to install and dismantle without any tools, save much time for installation and maintenance


6. Can be suspend or fixed installation, Seamless splicing,smooth surfacing and perfect vision effect

7. Widely used in public advertising, theatre, live show, live meeting, banquet, stage background,concert, show, event etc.
576X576mm Full Color LED Screen/Display Panel for Stage Background (P4.8, P6)


576X576mm Full Color LED Screen/Display Panel for Stage Background (P4.8, P6)
576X576mm Full Color LED Screen/Display Panel for Stage Background (P4.8, P6)
576X576mm Full Color LED Screen/Display Panel for Stage Background (P4.8, P6)
576X576mm Full Color LED Screen/Display Panel for Stage Background (P4.8, P6)

576X576mm Full Color LED Screen/Display Panel for Stage Background (P4.8, P6)

P4.8 SMD3528 Indoor full Color LED Screen Specification
Pixel pitch 4.8mm
Pixel Configuration 1R1G1B
LED component SMD3528
Size of module 288mm*288mm
Resolution of module 60x60
Size of cabinet 576mm x 576mm x 65mm
Resolution of cabinet 120x120
Material of Cabinet Die-casting Aluminum
Weight of Cabinet 10.50KGS
Brightness >1500cd/sq.m
Density 43042dots/sq.m
Best viewing angle 140 /140
Pixel Configuration 1R1G1B
Best viewing distance 3-50M
Maximum power consumption 1200W/sq.m
Average power consumption 640W/sq.m
Driving method 1/15 scan
Control method Synchronization
Gray scale 65536
Colors 256*256*256
Color temperature 3200-9300k
Uniformity 97%
Working voltage AC220V/110V±10%
Working temperature -20ºC~+50ºC±10%
Working humidity 10% ~ 90%
MTBF 10,000 hours
Frame frequence 50/60Hz
Refresh frequence >1920Hz
IP grade IP31
Life Span 100,000 hours
Data transafer method RJ45
Pratical standard CCC  TUV-CE  ETL etc.
Effectivce Communication
Distance(without relay)
Unshielded twisted pair net line transmission distance:100M, max transmission distance:130M; Multi-mode optic fiber: 500M;
Single-mode optic fiber: 10KM
Accepting signal with video processor PAL/NTSC/SECAM,S-Video;VGA;RGB;HDMI,DVI,Composite Video;SDI,DP etc.
Systems operating platform WINDOWS(WINXP,WIN7/8/10), and interfaces for secondary development
