P3-IR576
Video Display
1R,1G,1B
1/16 Scan
LED Video Display
IP31
576X576mm
192X192mm
PRT
Shenzhen
Full Color
3mm
111111dots/Sq.M
Win XP,Win 2000,98,Nt
Stage Performance, Advertising, Shopping Guide
CE, RoHS, CCC, FCC
Die-Casting Aluminum
64X64dots
CE, FCC. ROHS, 3C
8528591090
P3 Indoor Full Color LED Display Main Parameters | ||
Visual Characteristics | Unit | Value |
Pixel Pitch | mm | 3.0 |
Pixel Density | Dots/sq.m | 111111 |
Pixel Configuration | black body SMD2121 | |
Cabinet Resolution | dots | 192×192 |
Refresh Rate | Hz | ≥1920 |
View Angle(H/V) | ° | 140/140 |
Brightness | nits | ≥1500 |
Gray Scale | Bit | 16 |
IP Rating | 31 | |
Power Consumption(Max/Avg) | W/sq.m | 1200/500 |
Input Voltage(AC) | V | 110~220 |
Modular Characteristics | ||
Cabinet Size(W×H×D) | mm | 576×576 |
Cabinet Material | Die-casting Aluminum | |
Cabinet Weight | Kg | 7 |
Module Size(W×H) | mm | 192×192 |
Environment | ||
Operation Temperature | ºC | -20~+50 |
Operating Humidity | 10%~90% | |
Driving Mode | 1/16 Scan | |
Control Distance | Cat 5E <100m,Single mode fiber<10Km |
