Indoor Rental P4 LED Display Screen with Die-Casting Board (576X576mm)

  • P4, P4.8, P6

  • Video Display

  • 1R,1G,1B

  • 1/16 Scan

  • LED Video Display

  • IP31

  • 576X576mm

  • 288X288mm

  • PRT

  • Shenzhen

  • Full Color

  • 4mm

  • 62500dots/Sq.M

  • Win XP,Win 2000,Win7/8/10

  • Stage Performance, Advertising, Shopping Guide

  • CE, RoHS, CCC, FCC

  • Die-Casting Aluminum

  • 144X144dots

  • CE, FCC. ROHS, 3C

  • 8528591090

P4 Full Color LED Board for rental with Die-casting cabinet, high resolution, high contrast, high refresh rate and reasonable price

Product features:

1.Made with die-casting aluminum, keep the structure strong and durable

2.Slim and small cabinet size of 576× 576× 60mm, with only 10.5kgs

3.The cabinet is portable,convenient to transport and collect, and packed with flight cases, can move to any where,

4.Rental design, easy to install and dismantle without any tools, save much time
Can be suspend or fixed installation, Seamless splicing

5.SMD2121 black body leds, ensure wide view angle,and high contrast ratio

8.Aluminum material with good heat dissipation, lower power consumtion with only power supply and no fans, no noise caused, nenergy-saving and good environment protection,

7. Widely used in public advertising, theatre, live show, live meeting, banquet, stage background etc.

Indoor Rental P4 LED Display Screen with Die-Casting Board (576X576mm)
Indoor Rental P4 LED Display Screen with Die-Casting Board (576X576mm)
Indoor Rental P4 LED Display Screen with Die-Casting Board (576X576mm)

P4 SMD2121 Indoor full Color LED Screen Specification
Pixel pitch 4mm
Pixel Configuration 1R1G1B
LED component SMD2121
Size of module 288mm*288mm
Resolution of module 60x60
Size of cabinet 576mm x 576mm x 65mm
Resolution of cabinet 144 x144
Material of Cabinet Die-casting Aluminum
Weight of Cabinet 10.50KGS
Brightness >1500cd/sq.m
Density 62500dots/sq.m
Best viewing angle 140 /140
Pixel Configuration 1R1G1B
Best viewing distance 3-50M
Maximum power consumption 1200W/
Average power consumption 640W/
Driving method 1/16 scan
Control method Synchronization
Gray scale 65536
Colors 256*256*256
Color temperature 3200-9300k
Uniformity 97%
Working voltage AC220V/110V±10%
Working temperature -20ºC~+50ºC±10%
Working humidity 10% ~ 90%
MTBF 10,000 hours
Frame frequence 50/60Hz
Refresh frequence >1920Hz
IP grade IP31
Life Span 100,000 hours
Data transafer method RJ45
Pratical standard CCC  TUV-CE  ETL etc.
Effectivce Communication
Distance(without relay)
Unshielded twisted pair net line transmission distance:100M, max transmission distance:130M; Multi-mode optic fiber: 500M;
Single-mode optic fiber: 10KM
Accepting signal with video processor PAL/NTSC/SECAM,S-Video;VGA;RGB;HDMI,DVI,Composite Video;SDI,DP etc.
Systems operating platform WINDOWS(WINXP,WIN7/8/10), and interfaces for secondary development
