P20-DIP
IP65
1R, 1G, 1B
300W / m²
Static Scan
Advertising,Stage Performance,Rental
DIP346
16X16dots
PRT
CE, FCC. ROHS, 3C
8528591090
Full Color
20mm
Video Display
2500dots/Sq.M
LED Video Display
CE, RoHS, CCC, FCC
320X320mm
1280X960mm
Wooden Case or as Required
Shenzhen China
P20 Outdoor full Color LED Screen Specification | |
Pixel pitch | 20mm |
Pixel Configuration | 1R1G1B |
LED component | DIP346(Epistar) |
Size of module | 320mm x 320mm |
Resolution of module | 16x16 |
Size of cabinet | 1280mmx 960mm x150mm |
Resolution of cabinet | 64 x48dots |
Material of Cabinet | Iron with back doors |
Weight of Cabinet | <60KGS |
Brightness | >7500cd/sq.m |
Density | 2500dots/sq.m |
Best viewing angle | 110 /50 |
Best viewing distance | 15-200M |
Maximum power consumption | <600W/sq.m |
Average power consumption | <300W/sq.m |
Driving method | Static |
Control method | Synchronization |
Gray scale | 65536 |
Colors | 256*256*256 |
Color temperature | 3200-9300k |
Uniformity | 97% |
Working voltage | AC220V/110V±10% |
Working temperature | -20ºC~+50ºC±10% |
Working humidity | 10% ~ 90% |
MTBF | 10,000 hours |
Frame frequence | 50/60Hz |
Refresh frequence | >1800Hz |
IP grade | IP65 |
Life Span | 100,000 hours |
Data transafer method | RJ45 |
Pratical standard | CCC TUV-CE ETL etc. |
Effectivce Communication Distance(without relay) | Unshielded twisted pair net line transmission distance:100M, max transmission distance:130M; Multi-mode optic fiber: 500M; Single-mode optic fiber: 10KM |
Accepting signal with video processor | PAL/NTSC/SECAM,S-Video;VGA;RGB;HDMI,DVI,Composite Video;SDI,DP etc. |
Systems operating platform | WINDOWS(WINXP,WIN7/8/10), and interfaces for secondary development |
