DIP346 P16 Full Color LED Display Outdoor with High Brightness

Quantity:
  • P16
  • IP65
  • 1R, 1G, 1B
  • 300W / m⊃2;
  • Static Scan
  • Advertising,Stage Performance,Rental
  • DIP346
  • 16X16dots
  • PRT
  • Shenzhen China
  • Full Color
  • 16mm
  • Video Display
  • 3906dots/Sq.M
  • LED Video Display
  • CE, RoHS, CCC, RoHS
  • 256X256mm
  • 1024X768mm
  • CE, FCC. ROHS, 3C
  • 8528591090
DIP 346 P16 Full Color LED Display Outdoor with high brightness and competitive cost

Product Features:

1. DIP led encapsulation confirm the high brightness even under sunlight,

2.Good waterproof,IP65, Anti-corrosion,Antifogging,suit to any weather

3.High quality,with CE,Rohs,FCC certificates,and 2years warranty

4. High pixel density, Long vuew distance, High definition, Good uniformity

5. Brightness can be adjusted automatically according to different surrondings,can be set to open and close the screen on fixed automatically


6.Can be fixed on the wall, on the street, on top of building,or be hung for rental to meet the request of live broadcast, live meeting, banquet, party, etc, to display the content what you want, by video, graphics, antimation etc, connect with PC computer or network, also can remoto control with asynchronous system.


DIP346 P16 Full Color LED Display Outdoor with High Brightness

DIP346 P16 Full Color LED Display Outdoor with High Brightness
DIP346 P16 Full Color LED Display Outdoor with High Brightness

P16 Outdoor full Color LED Screen Specification
Pixel pitch 16mm
Pixel Configuration 1R1G1B
LED component DIP346(Epsitar chips)
Size of module 256mm x 256mm
Resolution of module 16x16
Size of cabinet 1024mmx 768mm x 150mm
Resolution of cabinet 64x48
Material of Cabinet Iron with back doors
Weight of Cabinet <50KGS
Brightness >7500cd/m2
Density 3906dots/m2
Best viewing angle 110 /50
Best viewing distance 15-200M
Maximum power consumption <800W/m2
Average power consumption <300W/m2
Driving method Static
Control method Synchronization
Gray scale 65536
Colors 256*256*256
Color temperature 3200-9300k
Uniformity 97%
Working voltage AC220V/110V±10%
Working temperature -20ºC~+50ºC±10%
Working humidity 10% ~ 90%
MTBF 10,000 hours
Frame frequence 50/60Hz
Refresh frequence >3000Hz
IP grade IP65
Life Span 100,000 hours
Data transafer method RJ45
Pratical standard CCC  TUV-CE  ETL etc.
Effectivce Communication
Distance(without relay)
Unshielded twisted pair net line transmission distance:100M, max transmission distance:130M; Multi-mode optic fiber: 500M;
Single-mode optic fiber: 10KM
Accepting signal with video processor PAL/NTSC/SECAM,S-Video;VGA;RGB;HDMI,DVI,Composite Video;SDI,DP etc.
Systems operating platform WINDOWS(WINXP,WIN7/8/10), and interfaces for secondary development
