High Resolution P10 Full Color Outdoor LED Display with Aluminum Panel

Quantity:
  • P10-outdoor SMD
  • IP65
  • 1R, 1G, 1B
  • 350W / m⊃2;
  • 1/4 Scan
  • Advertising, Stage Performance, Rental
  • SMD3535
  • 32X16dots
  • PRT
  • CE, FCC. ROHS, 3C
  • 8528591090
  • Full Color
  • 10mm
  • Video Display
  • 10000 dot / m⊃2;
  • LED Video Display
  • CE, RoHS, CCC, FCC
  • 320X160mm
  • >=7500nits
  • Wooden Case or as Required
  • Shenzhen China
P10 SMD3535 outdoor full color led display screen with die-casting aluminum cabinet size of 640x960, can be for fixed install and rental use,with good uniformity and high brightness

Product Features:

1.SMD led encapsulation confirm wide view angle and low power consumption

2. Good waterproof IP65,long life time


3. High resolution,high brightness,Long view distance,Good uniformity

4. With Rental design Aluminum Cabinet,low lightweight,easy and quick to assemble without tools in short time,and can be fixed installation or hung for rental

5. Low noise created,good heat dissipation,low transportation costs


6. Can be fixed installation or for rental to meet the request of live broadcast, live meeting, banquet, party, etc, to display the content what you want, connect with PC computer or network, also can remoto control with asynchronous system.

7. Widely used for commercial led display,advertising led display, stage led display,mobile led display. traffic led display,rental led display, sports led display etc.



High Resolution P10 Full Color Outdoor LED Display with Aluminum Panel
High Resolution P10 Full Color Outdoor LED Display with Aluminum Panel

High Resolution P10 Full Color Outdoor LED Display with Aluminum Panel High Resolution P10 Full Color Outdoor LED Display with Aluminum Panel





P10 Outdoor full Color LED Screen Specification
Pixel pitch 10mm
Pixel Configuration 1R1G1B
LED component SMD3535 black
Size of module 320mm x 160mm
Resolution of module 32x16
Size of cabinet 640mmx 960mmx70mm
Resolution of cabinet 64 x 96
Material of Cabinet Die-casting Aluminum
Weight of Cabinet <30KGS
Brightness >7500cd/sq.m
Density 10000dots/sq.m
Best viewing angle 140 /14
Best viewing distance 10-150M
Maximum power consumption <1000W/sq.m
Average power consumption <350W/sq.m
Driving method 1/2 scan
Control method Synchronization
Gray scale 65536
Colors 256*256*256
Color temperature 3200-9300k
Uniformity 97%
Working voltage AC220V±10%
Working temperature -20ºC~+50ºC±10%
Working humidity 10% ~ 90%
MTBF 10,000 hours
Frame frequence 50/60Hz
Refresh frequence >1800Hz
IP grade IP65
Life Span 100,000 hours
Data transafer method RJ45
Pratical standard CCC  TUV-CE  ETL etc.
Effectivce Communication
Distance(without relay)
Unshielded twisted pair net line transmission distance:100M, max transmission distance:130M; Multi-mode optic fiber: 500M;
Single-mode optic fiber: 10KM
Accepting signal with video processor PAL/NTSC/SECAM,S-Video;VGA;RGB;HDMI,DVI,Composite Video;SDI,DP etc.
Systems operating platform WINDOWS(WINXP,WIN7/8/10), and interfaces for secondary development
