Pixel 8mm
IP65
1R, 1G, 1B
350W / m²
1/5 Scan
Stage Performance, Advertising
SMD3535
40X20dots
Over 6000nits
Wooden Case
Shenzhen China
Full Color
8mm
Video Display
15625dots Per Sqm
LED Video Display
CE, RoHS, CCC, FCC
320X160mm
Iron/Aluminum
PRT
CE, FCC, Rohs
8528591090
P8 SMD Outdoor full Color LED Screen Specification | ||||||
Pixel pitch | 8mm | |||||
Size of module | 320mm χ 160mm | |||||
Resolution of module | 40 X 20 | |||||
Size of cabinet | 960mm X 960mm*150mm | |||||
Resolution of cabinet | 120*120 | |||||
Weight of Cabinet | <45KGS | |||||
Brightness | >6000cd/sq.m | |||||
Density | 15625dots/sq.m | |||||
Best viewing angle | 120 /120 | |||||
Pixel Configuration | 1R1G1B | |||||
Best viewing distance | 8-75M | |||||
Maximum power consumption | <800W/sq.m | |||||
Driving method | 1/5 scan | |||||
Control method | Synchronization | |||||
Gray scale | 16 bits | |||||
Colors | 16.7million | |||||
Color temperature | 6500k | |||||
Working voltage | AC220V/110V±10% | |||||
Working temperature | -20ºC~+50ºC±10% | |||||
MTBF | >10,000 hours | |||||
Frame frequence | 50/60Hz | |||||
Refresh frequence | >1800Hz | |||||
IP grade | IP65 | |||||
Life Span | 100,000 hours | |||||
Data transafer method | RJ45 | |||||
Effectivce Communication Distance(without relay) | Unshielded twisted pair net line transmission distance:100M, max transmission distance:130M; Multi-mode optic fiber: 500M; Single-mode optic fiber: 10KM | |||||
Systems operating platform | WINDOWS(WIN95,WIN2000,WINXP,WIN7), and interfaces for secondary development |
