P3.91
Video Display
1R,1G,1B
1/16 Scan
LED Video Display
IP31
SMD2121 Black
64X64dots
Aluminum Profile
Flight Case or Wooden Case
Shenzhen China
Full Color
3.91mm
65746dots/Sq.M
Win XP,Win 2000,98,Nt
Stage Performance, Advertising, Shopping Guide
CE, RoHS, CCC, FCC
250X250mm
500X500mm
PRT
CE, FCC, Rohs
8528591090
| P3.91 SMD2121 Indoor full Color LED Screen Specification | |
| Pixel pitch | 3.91mm |
| Pixel Configuration | 1R1G1B |
| LED component | SMD2121 black |
| Size of module | 250mm x 250mm |
| Resolution of module | 64x64dots |
| Size of cabinet | 500x500mm/500mm x 1000mm x 75mm |
| Resolution of cabinet | 128x128/128x256 dots |
| Material of Cabinet | Die-casting Aluminum/Aluminum |
| Weight of Cabinet | 8kgs/14kgs |
| Brightness | >1600cd/sq.m |
| Density | 65746dots/sq.m |
| Best viewing angle | 140 /140 |
| Pixel Configuration | 1R1G1B |
| Best viewing distance | 3-50M |
| Maximum power consumption | 1200W/sq.m |
| Average power consumption | 640W/sq.m |
| Driving method | 1/16 scan |
| Control method | Synchronization |
| Gray scale | 65536 |
| Colors | 256*256*256 |
| Color temperature | 3200-9300k |
| Uniformity | 97% |
| Working voltage | AC220V/110V±10% |
| Working temperature | -20ºC~+50ºC±10% |
| Working humidity | 10% ~ 90% |
| MTBF | 10,000 hours |
| Frame frequence | 50/60Hz |
| Refresh frequence | >1920Hz |
| IP grade | IP31 |
| Life Span | 100,000 hours |
| Data transafer method | RJ45 |
| Pratical standard | CCC TUV-CE ETL etc. |
| Effectivce Communication Distance(without relay) | Unshielded twisted pair net line transmission distance:100M, max transmission distance:130M; Multi-mode optic fiber: 500M; Single-mode optic fiber: 10KM |
| Accepting signal with video processor | PAL/NTSC/SECAM,S-Video;VGA;RGB;HDMI,DVI,Composite Video;SDI,DP etc. |
| Systems operating platform | WINDOWS(WINXP,WIN7/8/10), and interfaces for secondary development |
| P3.91 SMD2121 Indoor full Color LED Screen Specification | |
| Pixel pitch | 3.91mm |
| Pixel Configuration | 1R1G1B |
| LED component | SMD2121 black |
| Size of module | 250mm x 250mm |
| Resolution of module | 64x64dots |
| Size of cabinet | 500x500mm/500mm x 1000mm x 75mm |
| Resolution of cabinet | 128x128/128x256 dots |
| Material of Cabinet | Die-casting Aluminum/Aluminum |
| Weight of Cabinet | 8kgs/14kgs |
| Brightness | >1600cd/sq.m |
| Density | 65746dots/sq.m |
| Best viewing angle | 140 /140 |
| Pixel Configuration | 1R1G1B |
| Best viewing distance | 3-50M |
| Maximum power consumption | 1200W/sq.m |
| Average power consumption | 640W/sq.m |
| Driving method | 1/16 scan |
| Control method | Synchronization |
| Gray scale | 65536 |
| Colors | 256*256*256 |
| Color temperature | 3200-9300k |
| Uniformity | 97% |
| Working voltage | AC220V/110V±10% |
| Working temperature | -20ºC~+50ºC±10% |
| Working humidity | 10% ~ 90% |
| MTBF | 10,000 hours |
| Frame frequence | 50/60Hz |
| Refresh frequence | >1920Hz |
| IP grade | IP31 |
| Life Span | 100,000 hours |
| Data transafer method | RJ45 |
| Pratical standard | CCC TUV-CE ETL etc. |
| Effectivce Communication Distance(without relay) | Unshielded twisted pair net line transmission distance:100M, max transmission distance:130M; Multi-mode optic fiber: 500M; Single-mode optic fiber: 10KM |
| Accepting signal with video processor | PAL/NTSC/SECAM,S-Video;VGA;RGB;HDMI,DVI,Composite Video;SDI,DP etc. |
| Systems operating platform | WINDOWS(WINXP,WIN7/8/10), and interfaces for secondary development |
