Quantity: | |
---|---|
P2.5-400x300
Video Display
1R,1G,1B
1/30
LED Video Display
31
Black
200X300mm
PRT
CE, RoHs, FCC, CCC
8528591090
Full Color
2.5mm
160000 Dots/Sqm
Win XP,Win 2000,Win7/8
Stage Performance, Advertising, Shopping Guide, Meeting Room
CE, RoHS, CCC, FCC
SMD2121
400X300mm
Flight Case
Shenzhen China
P2.5 SMD1010 Indoor full Color LED Screen Specification | |
Pixel pitch | 2.5mm |
Pixel Configuration | 1R1G1B |
LED component | SMD1010 black |
Size of module | 200mm x 300mm |
Resolution of module | 80x120 |
Size of cabinet | 400mm x 300mm x 65mm |
Resolution of cabinet | 160x120 |
Material of Cabinet | Die-casting Aluminum |
Weight of Cabinet | 10.5KGS |
Brightness | <1200cd/sq.m |
Density | 160000dots/sq.m |
Best viewing angle | 160 /140 |
Pixel Configuration | 1R1G1B |
Best viewing distance | 2-30M |
Maximum power consumption | 1200W/sq.m |
Average power consumption | 640W/sq.m |
Driving method | 1/30 scan |
Control method | Synchronization |
Gray scale | 65536 |
Colors | 256*256*256 |
Color temperature | 3200-9300k |
Uniformity | 97% |
Working voltage | AC220V/110V±10% |
Working temperature | -20ºC~+50ºC±10% |
Working humidity | 10% ~ 90% |
MTBF | 10,000 hours |
Frame frequence | 50/60Hz |
Refresh frequence | >3000Hz |
IP grade | IP31 |
Life Span | 100,000 hours |
Data transafer method | RJ45 |
Pratical standard | CCC TUV-CE ETL etc. |
Effectivce Communication Distance(without relay) | Unshielded twisted pair net line transmission distance:100M, max transmission distance:130M; Multi-mode optic fiber: 500M; Single-mode optic fiber: 10KM |
Accepting signal with video processor | PAL/NTSC/SECAM,S-Video;VGA;RGB;HDMI,DVI,Composite Video;SDI,DP etc. |
Systems operating platform | WINDOWS(WINXP,WIN7/8/10), and interfaces for secondary development |
P2.5 SMD1010 Indoor full Color LED Screen Specification | |
Pixel pitch | 2.5mm |
Pixel Configuration | 1R1G1B |
LED component | SMD1010 black |
Size of module | 200mm x 300mm |
Resolution of module | 80x120 |
Size of cabinet | 400mm x 300mm x 65mm |
Resolution of cabinet | 160x120 |
Material of Cabinet | Die-casting Aluminum |
Weight of Cabinet | 10.5KGS |
Brightness | <1200cd/sq.m |
Density | 160000dots/sq.m |
Best viewing angle | 160 /140 |
Pixel Configuration | 1R1G1B |
Best viewing distance | 2-30M |
Maximum power consumption | 1200W/sq.m |
Average power consumption | 640W/sq.m |
Driving method | 1/30 scan |
Control method | Synchronization |
Gray scale | 65536 |
Colors | 256*256*256 |
Color temperature | 3200-9300k |
Uniformity | 97% |
Working voltage | AC220V/110V±10% |
Working temperature | -20ºC~+50ºC±10% |
Working humidity | 10% ~ 90% |
MTBF | 10,000 hours |
Frame frequence | 50/60Hz |
Refresh frequence | >3000Hz |
IP grade | IP31 |
Life Span | 100,000 hours |
Data transafer method | RJ45 |
Pratical standard | CCC TUV-CE ETL etc. |
Effectivce Communication Distance(without relay) | Unshielded twisted pair net line transmission distance:100M, max transmission distance:130M; Multi-mode optic fiber: 500M; Single-mode optic fiber: 10KM |
Accepting signal with video processor | PAL/NTSC/SECAM,S-Video;VGA;RGB;HDMI,DVI,Composite Video;SDI,DP etc. |
Systems operating platform | WINDOWS(WINXP,WIN7/8/10), and interfaces for secondary development |
