High Resolution P4.8 Indoor Rental LED Display with 576X576mm Panel

Quantity:



Inquire Add to Basket

Model NO.:
P4.8
Display Function:
Video Display
Pixel Configuration:
1R,1G,1B
Scanning Mode:
1/16 Scan
Display Type:
LED Video Display
IP Rating:
IP31
Cabinet Size:
576X576
Module Size:
288X288mm
Trademark:
PRT
Specification:
CE, FCC. ROHS, 3C
HS Code:
8528591090
Tube Chip Color:
Full Color
Pixel Pitch:
4.8mm
Pixel Density:
43402dots/Sq.M
System Operating Platform:
Win XP,Win 2000,98,Nt,Win7/8
Application:
Stage Performance, Advertising, Shopping Guide
Certification:
CE, RoHS, CCC, FCC
Cabinet Material:
Die-Casting Aluminum
Module Resolution:
60X60dots
Transport Package:
Flight Case or Wooden Case
Origin:
Shenzhen

Product Description

Full Color P4.8 Indoor Rental LED Display with Die-Casting cabinet size 576x576mm, slim thickness and light weight, high resolution and good uniformity

1.. Made with die-casting aluminum,strong profiles with beautiful outlooking and durable

2. Slim and small cabinet size of 576× 576× 65mm,only 12kgs,light weight and portable

3. No fans design, no noise created, low power consumption, energy-saving

4. Flight case package,convenient to transport and collect,can move to anywhere

5. Rental design, with fast locks and aviation plugs, easy to install and dismantle without any tools, save much time for installation and maintainance

6. Can be suspend or fixed installation, Seamless splicing,perfect display effect

7. Widely used in public advertising, theatre, live show, live meeting, banquet, stage background etc.

High Resolution P4.8 Indoor Rental LED Display with 576X576mm Panel

High Resolution P4.8 Indoor Rental LED Display with 576X576mm Panel

P4.8 SMD3528 Indoor full Color LED Screen Specification
Pixel pitch			4.8mm
Pixel Configuration			1R1G1B
LED component			SMD3528
Size of module			288mm x 288mm
Resolution of module			60x60
Size of cabinet			576mm x 576mm x 65mm
Resolution of cabinet			120x120
Material of Cabinet			Die-casting Aluminum
Weight of Cabinet			12KGS
Brightness			>1500cd/sq.m
Density			43402dots/sq.m
Best viewing angle			140 /140
Pixel Configuration			1R1G1B
Best viewing distance			3-50M
Maximum power consumption			1200W/sq.m
Average power consumption			640W/sq.m
Driving method			1/15 scan
Control method			Synchronization
Gray scale			65536
Colors			256256256
Color temperature			3200-9300k
Uniformity			97%
Working voltage			AC220V/110V±10%
Working temperature			-20ºC~+50ºC±10%
Working humidity			10% ~ 90%
MTBF			10,000 hours
Frame frequence			50/60Hz
Refresh frequence			>1920Hz
IP grade			IP31
Life Span			100,000 hours
Data transafer method			RJ45
Pratical standard			CCC TUV-CE ETL etc.
Effectivce Communication Distance(without relay)			Unshielded twisted pair net line transmission distance:100M, max transmission distance:130M; Multi-mode optic fiber: 500M; Single-mode optic fiber: 10KM
Accepting signal with video processor			PAL/NTSC/SECAM,S-Video;VGA;RGB;HDMI,DVI,Composite Video;SDI,DP etc.
Systems operating platform			WINDOWS(WINXP,WIN7/8/10), and interfaces for secondary development
