P6.25
PRT
8528591090
Competitive P6.25 SMD3535 Full Color LED Sign for outdoor display, to be fixed or be hung on truss for advertising, with 500x1000mm or 500x500mm die-casting Aluminum cabinet, light weight, high brightness,good stability
Product Features:
1.SMD3535 3 in 1 led encapsulation confirm wide view angle up to 140° for vertical and horizontal,and lower power consumption,energy saving
2. Good waterproof IP65, suit to any weather,anti-corrossion,long life span over 50000Hours
3. Die-casting Aluminum material cabinet with slim thickness of 75mm ensure light weight, only 13.5kgs per panel, can be picked up by one hand, easy to install and dismantle, better for rental use,
4. High brightness up to 6000nits, close view distance,good performance
5. Rental design cabinet with locks and aviation plugs, easy and quick to assemble without tools in short time, can be fixed install or hang on truss with flying bar
6. Dot to dot maintainance, quick maintain and save cost
7.No fans design, no noise caused, good environment protection
8. Widely used for stage, concert, show, banquet, wedding,stage background,public advertising etc.
9. We have other outlooking design cabinets for P3.91,P4.81,P5.95 and P6.25,with some different costs for customer's choosing,please contact us for details.
P6.25 Outdoor full Color LED Screen/Curtain Specification | |
Pixel pitch | 6.25mm |
Pixel Configuration | 1R1G1B |
LED component | SMD3535 |
Size of module | 250mm*250mm |
Resolution of module | 40x40 |
Size of cabinet | 500mmx500mm/ 500mm x 1000mm x 75mm |
Resolution of cabinet | 80x80/80x160dots |
Material of Cabinet | Die-casting Aluminum/Aluminum profile |
Weight of Cabinet | 8kgs/13.5KGS |
Brightness | >5500cd/sq.m |
Density | 25600dots/sq.m |
Best viewing angle | 140 /140 |
Pixel Configuration | 1R1G1B |
Best viewing distance | 6-100M |
Maximum power consumption | 800W/sq.m |
Average power consumption | 500W/sqm |
Driving method | 1/10 scan |
Control method | Synchronization |
Gray scale | 65536 |
Colors | 256*256*256 |
Color temperature | 3200-9300k |
Uniformity | 97% |
Working voltage | AC220V/110V±10% |
Working temperature | —20℃~+50℃±10% |
Working humidity | 10% ~ 90% |
MTBF | 10,000 hours |
Frame frequence | 50/60Hz |
Refresh frequence | >1920Hz |
IP grade | IP65 |
Life Span | 100,000 hours |
Data transafer method | RJ45 |
Pratical standard | CCC TUV-CE ETL etc. |
Effectivce Communication | Unshielded twisted pair net line transmission distance:100M, max transmission distance:130M; Multi-mode optic fiber: 500M; |
Accepting signal with video processor | PAL/NTSC/SECAM,S-Video;VGA;RGB;HDMI,DVI,Composite Video;SDI,DP etc. |
Systems operating platform | WINDOWS(WINXP,WIN7/8/10), and interfaces for secondary development |
