P5.95
PRT
8528591090
P5.95 Outdoor Full Color Display Screen for rental or fixed install,with 500x500mm panel,also can be 500x1000mm,high brightness and good uniformity
Product Features:
1. Made with SMD3535 led lamps, high resolution and wide view angle H140/V140
2.Seamless spliced,with smooth and vivid visual effect,perfect performance
3.Die-casting aluminum cabinets ensure lightweight and strong durable
4.Module size of 250x250mm, can be assembled with 500x500mm and 500x1000mm,
and can be some curved shapes with an angle adjuster
5.IP65 for front,and IP54 for back,good waterproof, can be used for outdoor against bad weather
6.High quality, producing according to the international standard of CE,FCC, Rohs,ETL
7.This cabinet design suit for outdoor/indoor P3.91, P4.81,P5.95
Outdoor Rental LED Display Panels | |||||
Model No. | P3.91 | P4.81 | P4.81 | P5.95 | P6.25 |
Pixel Pitch | 3.91mm | 4.81mm | 4.81mm | 5.95mm | 6.25mm |
Pixel Density (dots/sq.m) | 65536 | 43264 | 43264 | 28224 | 25600 |
LED component | SMD1921 | SMD1921 | SMD2727 | SMD2727 | SMD3535 |
Module Size | 250 x 250mm | 250 x 250mm | 250 X 250 mm | 250 x 250mm | 250 x 250mm |
Module Resolution (dots/sq.m) | 64 x 64 | 52x52 | 52 X 52 | 42 x 42 | 40 x 40 |
Panel Size | 500x500mm 500x1000mm | 500x500mm 500x1000mm | 500x500mm 500x1000mm | 500x500mm 500x1000mm | 500x500mm 500x1000mm |
Panel Weight | 8kgs 14kgs | 8kgs 14kgs | 8kgs 14kgs | 8kgs 14kgs | 8kgs 14kgs |
Brightness | ≥3500nits | ≥3500nits | ≥4500nits | ≥5500nits | ≥4000nits |
Best viewing distance | ≥3.9m | ≥4.8m | ≥4.8m | ≥6.0m | ≥6.2m |
Maximum power consumption | ≤800W/sq.m | ≤800W/sq.m | ≤800W/sq.m | ≤800W/sq.m | ≤800W/sq.m |
Driving method | 1/16 | 1/13 | 1/13 | 1/7 | 1/10 |
Control method | Synchronous control system ( connect with computer or video processor) | ||||
Uniformity | 97% | ||||
Working voltage | AC220V/110V±10% | ||||
Working temperature | —20℃~+50℃±10% | ||||
Working humidity | 10％ ～ 90％ | ||||
MTBF | 10,000 hours | ||||
Frame Frequence | 50/60Hz | ||||
Refresh Frequence | >2000Hz | ||||
IP grade | IP65 | ||||
Effective Communication | Unshielded twisted pair net line transmission distance:100M, max transmission distance:130M; Multi-mode optic fiber: 500M; | ||||
Accepting signal with video processor | PAL/NTSC/SECAM,S-Video;VGA;RGB;HDMI,DVI,Composite Video;SDI,DP etc. | ||||
Systems operating platform | WINDOWS(WINXP,WIN7/8/10), and interfaces for secondary development | ||||
