P6.25 outdoor led panel with 500x500mm/500x1000mm
IP65
1R, 1G, 1B
300W / m²
1/10 Scan
Advertising
SMD3535
Die-Casting Aluminum
IP65
CE, FCC. ROHS, 3C
8528591090
Full Color
6.25mm
Video Display
25600dots/Sq.M
LED Video Display
CE, RoHS, CCC
250X250mm
Synchronous
PRT
Shenzhen China
P6.25 full Color LED Screen/Curtain Specification | |
Pixel pitch | 6.25mm |
Pixel Configuration | 1R1G1B |
LED component | SMD3535 |
Size of module | 250mm*250mm |
Resolution of module | 40x40 |
Size of cabinet | 500mm*1000mm x 75mm or 500mm x 500mm |
Resolution of cabinet | 80x160 |
Material of Cabinet | Die-casting Aluminum |
Weight of Cabinet | 13KGS |
Brightness | >5500cd/ |
Density | 25600dots/ |
Best viewing angle | 140 /140 |
Pixel Configuration | 1R1G1B |
Best viewing distance | 6-100M |
Maximum power consumption | 1000W/ |
Average power consumption | 550W/ |
Driving method | 1/10 scan |
Control method | Synchronization |
Gray scale | 65536 |
Colors | 256*256*256 |
Color temperature | 3200-9300k |
Uniformity | 97% |
Working voltage | AC220V/110V±10% |
Working temperature | -20ºC~+50ºC±10% |
Working humidity | 10% ~ 90% |
MTBF | 10,000 hours |
Frame frequence | 50/60Hz |
Refresh frequence | >1920Hz |
IP grade | IP65 |
Life Span | 100,000 hours |
Data transafer method | RJ45 |
Pratical standard | CCC TUV-CE ETL etc. |
Effectivce Communication Distance(without relay) | Unshielded twisted pair net line transmission distance:100M, max transmission distance:130M; Multi-mode optic fiber: 500M; Single-mode optic fiber: 10KM |
Accepting signal with video processor | PAL/NTSC/SECAM,S-Video;VGA;RGB;HDMI,DVI,Composite Video;SDI,DP etc. |
Systems operating platform | WINDOWS(WINXP,WIN7/8/10), and interfaces for secondary development |
P6.25 full Color LED Screen/Curtain Specification | |
Pixel pitch | 6.25mm |
Pixel Configuration | 1R1G1B |
LED component | SMD3535 |
Size of module | 250mm*250mm |
Resolution of module | 40x40 |
Size of cabinet | 500mm*1000mm x 75mm or 500mm x 500mm |
Resolution of cabinet | 80x160 |
Material of Cabinet | Die-casting Aluminum |
Weight of Cabinet | 13KGS |
Brightness | >5500cd/ |
Density | 25600dots/ |
Best viewing angle | 140 /140 |
Pixel Configuration | 1R1G1B |
Best viewing distance | 6-100M |
Maximum power consumption | 1000W/ |
Average power consumption | 550W/ |
Driving method | 1/10 scan |
Control method | Synchronization |
Gray scale | 65536 |
Colors | 256*256*256 |
Color temperature | 3200-9300k |
Uniformity | 97% |
Working voltage | AC220V/110V±10% |
Working temperature | -20ºC~+50ºC±10% |
Working humidity | 10% ~ 90% |
MTBF | 10,000 hours |
Frame frequence | 50/60Hz |
Refresh frequence | >1920Hz |
IP grade | IP65 |
Life Span | 100,000 hours |
Data transafer method | RJ45 |
Pratical standard | CCC TUV-CE ETL etc. |
Effectivce Communication Distance(without relay) | Unshielded twisted pair net line transmission distance:100M, max transmission distance:130M; Multi-mode optic fiber: 500M; Single-mode optic fiber: 10KM |
Accepting signal with video processor | PAL/NTSC/SECAM,S-Video;VGA;RGB;HDMI,DVI,Composite Video;SDI,DP etc. |
Systems operating platform | WINDOWS(WINXP,WIN7/8/10), and interfaces for secondary development |
