P1.667
PRT
8528591090
Ultra HD P1.667 Full Color LED Screen with seamless spliced cabinet 400x300mm, good uniformity,high contrast and high gray scale, perfect display effect.
Specifications:
1. Ultra High definition, used as HD TV screen with full color (true color)
2.Seamless splice: no space/gap between the cabinet,ensure the good informance
3.High refresh rate, high gray scale and high contrast rate to 5000:1
4.Wide view angle, up to 160 degree, with same effection and no brightness difference
5. High reliability redundancy technique, with double power supply, when one is no work, another one will work automatically, ensure the cabinet keep working without any disturb.
6. With single point brightness and Chroma corrention technology,ensure the led screen in good uniformity
Advantages:
1.Support seamless splice for any sizes
2.Adjustable brightness, support 16Bit high gray scale,for images to be brightness and perfect details
3.High contrast ratio,fast response speed,high refresh rate, meet the high speed image display,and support 3D display
4.High efficiency heat dissipation, no fans no noise
5.Long life span to 100000Hours, low brightness attenuation,good uniformity
DESCRIPTION: | PH1.6 Indoor led video wall | ||
| No. | Parameter | Specification | |
| 1 | Pixel Pitch(mm) | 1.667 | |
| 2 | Pixel Density | 360000pix/sq.m | |
| 3 | LED Type | SMD1010 | |
| 4 | LED Wave Length(nm) | R:620-625/G:517.5-520/B:465-467.5 | |
| 5 | LED Luminous Intensity(mcd) | R:100~130/G:120~156/B:20~26 | |
| 6 | Viewing Angle | 160° | |
| 7 | Brightness | 1000cd/ | |
| 8 | Drive Method | constant current | |
| 9 | Driving IC | MBI5153 | |
| 10 | Color Depth | 16bit | |
| 11 | Refresh Rate(Hz) | 1200 | |
| 12 | Frame Rate(Hz) | ≥60 | |
| 13 | Brightness Adjustment | Manual/Auto/Program | |
| 14 | Module Size(mm) | 200×150 | |
| 15 | Module Resolution() | 120×90 | |
| 16 | Cabinet Size(mm) | 400×300 | |
| 17 | Cabinet Display Resolution() | 240×180 | |
| 18 | Cabinet Type and Material | Die-casting Aluminum | |
| 19 | Cabinet Weight(Kg) | 5.0kg | |
| 20 | Power Supply | 5.0V 40A | |
| 21 | Voltage(V) | AC 220V | |
| 22 | Avg. Power Consumption | 40W/cabinet | |
| 23 | Max. Power Consumption | 120W/cabinet | |
| 24 | Service Access | Back maintenance | |
| 25 | IP Grade | IP31 | |
| 26 | Operating Temp/Humidity | -20ºC~50ºC, 10~90%RH | |
| 27 | Storage Temp/Humidity | -40ºC~60ºC, 10~90%RH | |
| 28 | Lifetime(Normal Temp) | ≥50000H | |
| 29 | System Control | Nova/Linsn | |
| 30 | Compliant Standard | CCC,CE,RoHs | |
