Quantity: | |
---|---|
P4-outdoor
IP65
1R, 1G, 1B
600W / m²
1/8 Scan
Advertising, Stage Performance, Rental
576 X 576mm
192 X 192mm
PRT
CE, FCC. ROHS, 3C
8528591090
Full Color
4mm
Video Display
62500dots/Sq.M
LED Video Display
CE, RoHS, CCC, FCC
Die-Casting Aluminum
48 X 48dots
Flight Case or Wooden Case
Shenzhen
P4 SMD1921 Indoor full Color LED Screen Specification | ||||||
Pixel pitch | 4mm | |||||
Pixel Configuration | 1R1G1B | |||||
LED component | SMD1921 | |||||
Size of module | 192mm x 192mm | |||||
Resolution of module | 48x48 | |||||
Size of cabinet | 576mm x 576mm x 65mm | |||||
Resolution of cabinet | 128x128 | |||||
Material of Cabinet | Die-casting Aluminum | |||||
Weight of Cabinet | 12.5KGS | |||||
Brightness | >4500cd/sq.m | |||||
Density | 62500dots/sq.m | |||||
Best viewing angle | 140 /140 | |||||
Pixel Configuration | 1R1G1B | |||||
Best viewing distance | 3-50M | |||||
Maximum power consumption | 1000W/sq.m | |||||
Average power consumption | 600W/sq.m | |||||
Driving method | 1/8 scan | |||||
Control method | Synchronization | |||||
Gray scale | 65536 | |||||
Colors | 256*256*256 | |||||
Color temperature | 3200-9300k | |||||
Uniformity | 97% | |||||
Working voltage | AC220V/110V±10% | |||||
Working temperature | -20ºC~+50ºC±10% | |||||
Working humidity | 10% ~ 90% | |||||
MTBF | 10,000 hours | |||||
Frame frequence | 50/60Hz | |||||
Refresh frequence | >3000Hz | |||||
IP grade | IP65 | |||||
Life Span | 100,000 hours | |||||
Data transafer method | RJ45 | |||||
Pratical standard | CCC TUV-CE ETL etc. | |||||
Effectivce Communication Distance(without relay) | Unshielded twisted pair net line transmission distance:100M, max transmission distance:130M; Multi-mode optic fiber: 500M; Single-mode optic fiber: 10KM | |||||
Accepting signal with video processor | PAL/NTSC/SECAM,S-Video;VGA;RGB;HDMI,DVI,Composite Video;SDI,DP etc. | |||||
Systems operating platform | WINDOWS(WINXP,WIN7/8/10), and interfaces for secondary development |
P4 SMD1921 Indoor full Color LED Screen Specification | ||||||
Pixel pitch | 4mm | |||||
Pixel Configuration | 1R1G1B | |||||
LED component | SMD1921 | |||||
Size of module | 192mm x 192mm | |||||
Resolution of module | 48x48 | |||||
Size of cabinet | 576mm x 576mm x 65mm | |||||
Resolution of cabinet | 128x128 | |||||
Material of Cabinet | Die-casting Aluminum | |||||
Weight of Cabinet | 12.5KGS | |||||
Brightness | >4500cd/sq.m | |||||
Density | 62500dots/sq.m | |||||
Best viewing angle | 140 /140 | |||||
Pixel Configuration | 1R1G1B | |||||
Best viewing distance | 3-50M | |||||
Maximum power consumption | 1000W/sq.m | |||||
Average power consumption | 600W/sq.m | |||||
Driving method | 1/8 scan | |||||
Control method | Synchronization | |||||
Gray scale | 65536 | |||||
Colors | 256*256*256 | |||||
Color temperature | 3200-9300k | |||||
Uniformity | 97% | |||||
Working voltage | AC220V/110V±10% | |||||
Working temperature | -20ºC~+50ºC±10% | |||||
Working humidity | 10% ~ 90% | |||||
MTBF | 10,000 hours | |||||
Frame frequence | 50/60Hz | |||||
Refresh frequence | >3000Hz | |||||
IP grade | IP65 | |||||
Life Span | 100,000 hours | |||||
Data transafer method | RJ45 | |||||
Pratical standard | CCC TUV-CE ETL etc. | |||||
Effectivce Communication Distance(without relay) | Unshielded twisted pair net line transmission distance:100M, max transmission distance:130M; Multi-mode optic fiber: 500M; Single-mode optic fiber: 10KM | |||||
Accepting signal with video processor | PAL/NTSC/SECAM,S-Video;VGA;RGB;HDMI,DVI,Composite Video;SDI,DP etc. | |||||
Systems operating platform | WINDOWS(WINXP,WIN7/8/10), and interfaces for secondary development |
