High Brightness P6 Outdoor LED Digital Signage

Quantity:
  • P6-outdoor
  • IP65
  • 1R, 1G, 1B
  • 350W / m⊃2;
  • 1/8 Scan
  • Advertising, Stage Performance, Rental
  • SMD3535
  • 576X576mm
  • PRT
  • Shenzhen China
  • Full Color
  • 6mm
  • Video Display
  • 27777dots/Sq.M
  • LED Video Display
  • CE, RoHS, CCC
  • 288X288mm
  • 96X96dots
  • CE, FCC. ROHS, 3C
  • 8528591090
High Brightness P6 Outdoor LED Digital Signage with Full Color to display text, images,dynamic videos, good uniformity and high definition, made with waterproof cabinet for outdoor permanent install or rental use

Product Features:

1. SMD led encapsulation confirm wide view angle,

2. Good waterproof IP65, long life span>100000Hours

3. High pixel density, Long view distance, High definition, Good uniformity

4. Cables connected with aviation plugs, easy and quick to connect between cabinets

5. Low power consumption, low noise created, low transportation costs

6. Can be fixed installation or for rental to meet the request of live broadcast, live meeting, banquet, party, etc, to display the content what you want, connect with PC computer or network, also can remoto control with asynchronous system.


High Brightness P6 Outdoor LED Digital Signage
High Brightness P6 Outdoor LED Digital Signage
High Brightness P6 Outdoor LED Digital Signage


     Outdoor P6  Full Color LED Display Main Parameters
Visual Characteristics Unit Value
Pixel Pitch mm 6.0
Pixel Density Dots/sq.m 27777
Pixel Configuration
SMD3535
Cabinet Resolution dots 160×160
Refresh Rate Hz ≥1920
View Angle(H/V) ° 140/140
Brightness nits ≥5000
Gray Scale Bit 16
IP Rating
65
Power Consumption(Max/Avg) W/sq.m 1000/400
Input Voltage(AC) V 110~240
Modular Characteristics
Cabinet Size(W×H×D) mm 960×960
Cabinet Material
Iron/Aluminum/Iron
Cabinet Weight Kg 45/40
Module Size(W×H) mm 192x192
Environment
Operation Temperature ºC -20~+50
Operating Humidity
10%~90%
Driving Mode
1/8 Scan
Control Distance Cat 5E <100m,Single mode fiber<10Km
