High Brightness P8 Full Color LED Dynamic Image Wall

Quantity:
  • P8 led wall
  • IP65
  • 1R, 1G, 1B
  • 350W / m⊃2;
  • 1/5 Scan
  • Stage Performance, Advertising
  • SMD3535
  • 40X20dots
  • Iron
  • CE, FCC, Rohs
  • 8528591090
  • Full Color
  • 8mm
  • Video Display
  • 15625dots Per Sqm
  • LED Video Display
  • CE, RoHS, CCC, FCC
  • 320X160mm
  • 960X960mm
  • PRT
  • Shenzhen China
Full Color Outdoor P8 LED Sign for advertising with high brightness, good uniformity, good stability and good waterproof, sold very well with reasonable cost.

Product Features:

1. SMD led encapsulation technology confirm the wide view angle and good uniformity

2.High quality leds with black body with high contrast,high brightness up to 6000nits

3. Good Waterproof IP65, can be used under heavy rain weather and humid area

4. Stability Iron cabinets for fixed installation, with fast lock and aviation plugs, conveninet to install and dismantle

5. High quality, meet the request of international standard of CE, FCC,RoHs

6. Long life span >100000hours, and 3 year warranty

More pictures for reference:






P8 SMD Outdoor full Color LED Screen Specification
Pixel pitch 8mm
Size of module 320mm χ 160mm
Resolution of module 40 X 20
Size of cabinet 960mm X 960mm x150mm
Resolution of cabinet 120 x120
Weight of Cabinet <45KGS
Brightness >6000cd/sq.m
Density 15625dots/sq.m
Best viewing angle 120 /120
Pixel Configuration 1R1G1B
Best viewing distance 8-75M
Maximum power consumption <1000W/sq.m
Driving method 1/5 scan
Control method Synchronization
Gray scale 16 bits
Colors 16.7million
Color temperature 6500k
Working voltage AC220V/110V±10%
Working temperature -20ºC~+50ºC±10%
MTBF >10,000 hours
Frame frequence ≥60Hz
Refresh frequence >1800Hz
IP grade IP65
Life Span 100,000 hours
Data transafer method RJ45
Effectivce Communication
Distance(without relay)
Unshielded twisted pair net line transmission distance:100M, max transmission distance:130M; Multi-mode optic fiber: 500M;
Single-mode optic fiber: 10KM
Systems operating platform WINDOWS(WIN95,WIN2000,WINXP,WIN7), and interfaces for secondary development
