Indoor P6 LED Advertising Board with Cabinets 576X576mm

Quantity:



Inquire Add to Basket

Model NO.:
P6-576
Display Function:
Video Display
Pixel Configuration:
1R,1G,1B
Scanning Mode:
1/8 Scan
Display Type:
LED Video Display
IP Rating:
IP43
Cabinet Size:
576X576
Module Size:
288X288mm
Trademark:
PRT
Origin:
Shenzhen
Tube Chip Color:
Full Color
Pixel Pitch:
6mm
Pixel Density:
27777dots/Sq.M
System Operating Platform:
Win XP,Win 2000
Application:
Stage Performance, Advertising, Shopping Guide
Certification:
CE, RoHS, CCC, FCC
Cabinet Material:
Die-Casting Aluminum
Module Resolution:
96X96dots
Specification:
CE, FCC. ROHS, 3C
HS Code:
8528591090

Product Description

Indoor P6 LED Advertising Board with cabinets 576x576mm

Product Description:

1. Made with aluminum alloy wiht very light weight

2. Slim and small cabinet size of 576× 576× 60mm

3. It is portable and can be moved to any where

4. Rental design, easy to install and dismantle without any tools

5. Can be suspend or fixed installation, Seamless splicing

6. High brightness, good display performance and cost performance

7. Wide view angle, good heat dissipation,no fans no noise

9.Packed with flightcase or wooden case as required

10. Widely used in public advertising, theatre, live show, live meeting, banquet, stage background etc.

11. This rental cabinet design is available to indoor P4.8, P5.33,P6,P4

Indoor P6 Full Color LED Display Main Parameters
Visual Characteristics	Unit	Value
Pixel Pitch	mm	6.0
Pixel Density	Dots/sq.m	27777
Pixel Configuration		SMD3528
Cabinet Resolution	dots	96×96
Refresh Rate	Hz	≥1200
View Angle(H/V)	°	150/120
Brightness	nits	≥2000
Gray Scale	Bit	687Million
IP Rating		43
Power Consumption(Max/Avg)	W/sq.m	1200/500
Input Voltage(AC)	V	110~240
Modular Characteristics
Cabinet Size(W×H×D)	mm	576×576
Cabinet Material		Die-casting Aluminum
Cabinet Weight	Kg	9.0
Module Size(W×H)	mm	288×288
Environment
Operation Temperature	ºC	-20~+50
Operating Humidity		10%~90%
Driving Mode		1/8 Scan
Control Distance	Cat 5E <100m,Single mode fiber<10Km
