Outdoor/ Indoor Full Color LED Display Screen with 500X500mm/500X1000mm Panel (P3.91/P4.81/P6.25)

Quantity:
  • P4.81
  • IP65
  • 1R, 1G, 1B
  • 300W / m⊃2;
  • 1/13 Scan
  • Stage Performance, Advertising, Rental
  • SMD2727
  • 104X104 Dots
  • PRT
  • CE, ROHS, FCC, ETL
  • 8528591090
  • Full Color
  • 4.81mm
  • Video Display
  • 43264dots/Sq.M
  • LED Video Display
  • CE, RoHS, ETL
  • 500X500mm
  • 250X250mm
  • Flight Case
  • Shenzhen China
Outdoor P4.81 Full Color LED Display panel is more popular presently,with high brightness up to 6000nits,cabinet size can be 500x500mm or 500x1000mm,

Product Features:

1. Made with SMD2727 led lamps, high contrast and wide view angle140/140

2.Seamless spliced,with smooth and vivid visual effect,perfect performance

3.Die-casting aluminum cabinets ensure lightweight and strong durable

4.Module size of 250x250mm,  can be assembled with 500x500mm and 500x1000mm

5.IP65 for front,and IP54 for back , good waterproof, can be used for outdoor when it is raining

6.High quality, producing according to the international standard of CE,FCC, Rohs,ETL

7. The cabinet design suit for outdoor P4.81/P6.25/P5.95 or indoor P3.91, P4.81,P5.68,P5.95,P6.25

More pictures as below:

Outdoor/ Indoor Full Color LED Display Screen with 500X500mm/500X1000mm Panel (P3.91/P4.81/P6.25)



Outdoor/ Indoor Full Color LED Display Screen with 500X500mm/500X1000mm Panel (P3.91/P4.81/P6.25)
Outdoor/ Indoor Full Color LED Display Screen with 500X500mm/500X1000mm Panel (P3.91/P4.81/P6.25)
Outdoor/ Indoor Full Color LED Display Screen with 500X500mm/500X1000mm Panel (P3.91/P4.81/P6.25)
Outdoor/ Indoor Full Color LED Display Screen with 500X500mm/500X1000mm Panel (P3.91/P4.81/P6.25)
Outdoor/ Indoor Full Color LED Display Screen with 500X500mm/500X1000mm Panel (P3.91/P4.81/P6.25)


P4.81 Outdoor full Color LED Screen Specification
Pixel pitch 4.81mm
Pixel Configuration 1R1G1B
LED component SMD2727 black
Size of module 250mm x 250mm
Resolution of module 52x52
Size of cabinet 500mm x 500mm x 75mm
Resolution of cabinet 104x104
Material of Cabinet Die-casting Aluminum
Weight of Cabinet 7.8KGS
Brightness >6000cd/sq.m
Density 43264dots/sq.m
Best viewing angle 140 /140
Pixel Configuration 1R1G1B
Best viewing distance 3-60M
Maximum power consumption 1200W/sq.m
Average power consumption 640W/sq.m
Driving method 1/13 scan
Control method Synchronization
Gray scale 65536
Colors 256*256*256
Color temperature 3200-9300k
Uniformity 97%
Working voltage AC220V/110V±10%
Working temperature -20ºC~+50ºC±10%
Working humidity 10% ~ 90%
MTBF 10,000 hours
Frame frequence 50/60Hz
Refresh frequence >3000Hz
IP grade IP65
Life Span 100,000 hours
Data transafer method RJ45
Pratical standard CCC  TUV-CE  ETL etc.
Effectivce Communication
Distance(without relay)
Unshielded twisted pair net line transmission distance:100M, max transmission distance:130M; Multi-mode optic fiber: 500M;
Single-mode optic fiber: 10KM
Accepting signal with video processor PAL/NTSC/SECAM,S-Video;VGA;RGB;HDMI,DVI,Composite Video;SDI,DP etc.
Systems operating platform WINDOWS(WINXP,WIN7/8/10), and interfaces for secondary development
