P6.67, P8, P10 led panel
IP65
1R, 1G, 1B
350W / m²
1/8 Scan
Advertising,Stage Performance,Rental
SMD3535
640X640mm
PRT
Shenzhen China
Full Color
6.67mm
Video Display
22478dots/Sq.M
LED Video Display
CE, RoHS, CCC, RoHS
320X160mm
Die-Casting Aluminum
CE, FCC. ROHS, 3C
8528591090
Outdoor P6.67 Full Color LED Display Main Parameters | ||
Visual Characteristics | Unit | Value |
Pixel Pitch | mm | 6.67 |
Pixel Density | Dots/sq.m | 22478 |
Pixel Configuration | SMD3535 | |
Cabinet Resolution | dots | 96×96 |
Refresh Rate | Hz | ≥1920 |
View Angle(H/V) | ° | 140/140 |
Brightness | nits | ≥5500 |
Gray Scale | Bit | 16 |
IP Rating | 65 | |
Power Consumption(Max/Avg) | W/sq.m | 1000/300 |
Input Voltage(AC) | V | 110~240 |
Modular Characteristics | ||
Cabinet Size(W×H×D) | mm | 640×640 |
Cabinet Material | Die-cast Aluminum | |
Cabinet Weight | Kg | 13.5 |
Module Size(W×H) | mm | 320×160 |
Environment | ||
Operation Temperature | ºC | -20~+50 |
Operating Humidity | 10%~90% | |
Driving Mode | 1/8 Scan | |
Control Distance | Cat 5E <100m,Single mode fiber<10Km |
Outdoor P6.67 Full Color LED Display Main Parameters | ||
Visual Characteristics | Unit | Value |
Pixel Pitch | mm | 6.67 |
Pixel Density | Dots/sq.m | 22478 |
Pixel Configuration | SMD3535 | |
Cabinet Resolution | dots | 96×96 |
Refresh Rate | Hz | ≥1920 |
View Angle(H/V) | ° | 140/140 |
Brightness | nits | ≥5500 |
Gray Scale | Bit | 16 |
IP Rating | 65 | |
Power Consumption(Max/Avg) | W/sq.m | 1000/300 |
Input Voltage(AC) | V | 110~240 |
Modular Characteristics | ||
Cabinet Size(W×H×D) | mm | 640×640 |
Cabinet Material | Die-cast Aluminum | |
Cabinet Weight | Kg | 13.5 |
Module Size(W×H) | mm | 320×160 |
Environment | ||
Operation Temperature | ºC | -20~+50 |
Operating Humidity | 10%~90% | |
Driving Mode | 1/8 Scan | |
Control Distance | Cat 5E <100m,Single mode fiber<10Km |
