Slim Aluminum LED Display Panel with 500X500mm (Indoor P3.91)

  • P3.91

  • Video Display

  • 1R,1G,1B

  • 1/16

  • LED Video Display

  • IP43

  • SMD2121 Black

  • 104X104mm

  • PRT

  • CE, FCC, Rohs

  • 8528591090

  • Full Color

  • 3.91mm

  • 65746dots/Sq.M

  • WIN XP

  • Stage Performance, Advertising, Shopping Guide

  • CE, RoHS, CCC, FCC

  • 250X250mm

  • Aluminum Profile

  • Flight Case or as Required

  • Shenzhen China

New Design P3.91 Indoor LED Dispaly Panel made with slim aluminum panel,and size of 500x500mm for rental with light weight 6.8kgs

Product Features:

1. Light weight and super thin, less than 75mm thickness, easy to move, and portable

3. Rental design cabinet, can be fixed or hung,and easy to install and dismantle

4. Exquisite and tasteful appearance due to structural wire layout

5. Black body leds ensure high contrast ratio, high gray scale and high refresh rate

6. Wide view angle, up to 140
° for horizontal and vertical

7. Packed with flight case, convenient to be collected and transportation

More pictures for reference:
Slim Aluminum LED Display Panel with 500X500mm (Indoor P3.91)
Slim Aluminum LED Display Panel with 500X500mm (Indoor P3.91)

Slim Aluminum LED Display Panel with 500X500mm (Indoor P3.91)
Slim Aluminum LED Display Panel with 500X500mm (Indoor P3.91)

Related parameters as following:
P3.91 SMD2121 Indoor full Color LED Screen Specification
Pixel pitch 3.91mm
Size of module 250mm x 250mm
Resolution of module 64x64
Size of cabinet 500x500mm
Resolution of cabinet 128 x 128dots
Weight of Cabinet 6.8kgs
Brightness >1200cd/sq.m
Density 65746dots/sq.m
Best viewing angle 140 /140
Pixel Configuration 1R1G1B
Best viewing distance 3-50M
Maximum power consumption <1200W/sq.m
Driving method 1/16 scan
Control method Synchronization
Gray scale 65536
Colors 256*256*256
Color temperature 6500k
Working voltage AC220V/110V±10%
Working temperature -20ºC~+50ºC±10%
MTBF >10,000 hours
Frame frequence ≥60Hz
Refresh frequence >1920Hz
IP grade IP31
Life Span 100,000 hours
Data transafer method RJ45
Effectivce Communication
Distance(without relay)
Unshielded twisted pair net line transmission distance:100M, max transmission distance:130M; Multi-mode optic fiber: 500M;
Single-mode optic fiber: 10KM
Systems operating platform WINDOWS(WINXP,WIN7/8), and interfaces for secondary development
