Slim P6 Rental Indoor LED Screen (768X768mm Aluminum cabinet)

Quantity:
  • P6-768
  • Video Display
  • 1R,1G,1B
  • 1/8 Scan
  • LED Video Display
  • IP43
  • 768X768mm
  • 192X192mm
  • PRT
  • CE, FCC. ROHS, 3C
  • 8528591090
  • Full Color
  • 6mm
  • 27777dots/Sq.M
  • Win XP,Win 2000,Win7/8
  • Stage Performance, Advertising, Shopping Guide
  • CE, RoHS, CCC, FCC
  • Aluminum Alloy
  • SMD3528
  • Flight Case or Wooden Case
  • Shenzhen
P6 Indoor LED Screen with 768x768mm Aluminum cabinet with light weight and slim thickness, for indoor rental or fixed permanent install

Product Description:

1. Made with aluminum alloy with very light weight

2. Super thin cabinet size ,only 60mm thickness

3. Rental design, easy to install and dismantle without any tools

4. Seamless splicing,good heat dissipation,Low noise

5. High brightness, good display performance and cost performance

6. Wide view angle,good heat dissipation

7. 2 years quality warranty, according to the international standard of FCC,CE,Rohs etc.

8. Packed with flightcase or wooden case as required

9. Widely used in public advertising, shopping mall, theatre, live show, live meeting, banquet, stage background etc.

Slim P6 Rental Indoor LED Screen (768X768mm Aluminum cabinet)
Slim P6 Rental Indoor LED Screen (768X768mm Aluminum cabinet)
Slim P6 Rental Indoor LED Screen (768X768mm Aluminum cabinet)

Slim P6 Rental Indoor LED Screen (768X768mm Aluminum cabinet)
Slim P6 Rental Indoor LED Screen (768X768mm Aluminum cabinet)

Slim P6 Rental Indoor LED Screen (768X768mm Aluminum cabinet)


P6 SMD3528 Indoor full Color LED Screen Specification
Pixel pitch 6mm
Pixel Configuration 1R1G1B
LED component SMD3528
Size of module 384mm X 192mm
Resolution of module 64 x32
Size of cabinet 768mm x768mm x 60mm
Resolution of cabinet 128x128
Material of Cabinet Aluminum Profile
Weight of Cabinet 10KGS
Brightness >1500cd/sq.m
Density 27777dots/sq.m
Best viewing angle 140 /140
Pixel Configuration 1R1G1B
Best viewing distance 5-60M
Maximum power consumption 600W/sq.m
Average power consumption 360W/sq.m
Driving method 1/8 scan
Control method Synchronization
Gray scale 65536
Colors 256*256*256
Color temperature 3200-9300k
Uniformity 97%
Working voltage AC220V/110V±10%
Working temperature -20ºC~+50ºC±10%
Working humidity 10% ~ 90%
MTBF 10,000 hours
Frame frequence 50/60Hz
Refresh frequence >1920Hz
IP grade IP31
Life Span 100,000 hours
Data transafer method RJ45
Pratical standard CCC  TUV-CE  ETL etc.
Effectivce Communication
Distance(without relay)
Unshielded twisted pair net line transmission distance:100M, max transmission distance:130M; Multi-mode optic fiber: 500M;
Single-mode optic fiber: 10KM
Accepting signal with video processor PAL/NTSC/SECAM,S-Video;VGA;RGB;HDMI,DVI,Composite Video;SDI,DP etc.
Systems operating platform WINDOWS(WINXP,WIN7/8/10), and interfaces for secondary development
