SMD3535 Outdoor P5 LED Module with High Brightness

Quantity:
  • P5-Outdoor module

  • RGB

  • 3W

  • IP65

  • SMD2727

  • 32X32mm

  • PRT

  • Shenzhen China

  • Epsitar

  • <0.3W

  • Epistar

  • Waterproof

  • 160X160mm

  • Steel Iron

  • CE, RoHs, FCC, CCC

  • 8528591090

Full Color SMD2727 P5 LED Module/ full color led display module with good waterproof and high brightness for outdoor rental or fixed install

1) SMD led encapsultion with wide view angle to 120 degree, and short view distance

2) Unique lighting distribution curve, ensure visual effect is perfect seeing from different angle

3) High definition, smooth and good quality vision

4) Dot to dot maintain, easy and quick maintenance, save maintenance cost

5) High brightness up to 6000cd/sq.m

6) Can be assembled with cabinets or on rackes with magnets

More pictures for good understanding:

SMD3535 Outdoor P5 LED Module with High Brightness

SMD3535 Outdoor P5 LED Module with High Brightness
SMD3535 Outdoor P5 LED Module with High Brightness
     Outdoor  P5 Full Color LED Display Main Parameters
Visual Characteristics Unit Value
Pixel Pitch mm 5.0
Pixel Density Dots/sq.m 40000
Pixel Configuration
SMD2727
Module Resolution dots 32×32
Refresh Rate Hz ≥1800
View Angle(H/V) ° 120/120
Brightness nits ≥6000
Gray Scale Bit 16
IP Rating
65
Power Consumption(Max/Avg) W/sq.m 800/300
Input Voltage(AC) V 110~240
Modular Characteristics
Cabinet Size(W×H×D) mm 640χ640
Cabinet Material
Iron
Cabinet Weight Kg 15kgs
Module Size(W×H) mm 160×160
Environment
Operation Temperature ºC -20~+50
Operating Humidity
10%~90%
Driving Mode
1/8 Scan
Control Distance Cat 5E <100m,Single mode fiber<10Km
